Cpu
build in amd am4 socket processors *
* refer to www.asus.com for cpu support list
chipset
amd a520
memory
2 x dimm – max. 64gb – ddr4
4600(o.c) – 4400(o.c) – 4000(o.c.) – 3866(o.c.) – 3733
(o.c.) – 3600(o.c.) – 3466(o.c.) – 3333(o.c.) – 3200 – 3000 – 2800 – 2666 – 2400 – 2133
mhz un – buffered memory *
dual channel memory architecture
ecc memory (ecc mode) support varies by cpu.
* refer to www.asus.com for the memory qvl (qualified vendors lists).
* the maximum memory frequency supported varies by processor.
graphic
1 x d – sub
1 x hdmi 2.1(4k@60hz)
expansión slots
3rd gen amd ryzen and 3rd gen amd ryzen with radeon graphics
processors
1 x pcie 3.0 x16 (x16 mode)
amd a520 chipset
2 x pcie 3.0 x1
storage
total supports 1 x m.2 slot(s) and 4 x sata 6gb – s ports
3rd gen amd ryzen and 3rd gen amd ryzen with radeon graphics
processors :
1 x m.2 socket 3 – with m key – type 2242 – 2260 – 2280 (pcie 3.0 x4 and sata
modes) storage devices support
amd a520 chipset :
4 x sata 6gb – s port(s) –
support raid 0 – 1 – 10
lan
realtek rtl8111h 1gb ethernet
asus languard
audio
realtek alc887 7.1 surround sound high definitión audio codec *
– supports : jack – detectión – multi – streaming – front panel jack – retasking –
up to 24 – bit – 192khz playback
audio feature :
– audio shielding
– dedicated audio pcb layers
* choose the chassis with hd audio module in front panel to support
8 – channel audio output.
usb ports
rear usb port ( total 6 )
4 x usb 3.2 gen 1 port(s)(4 x type – a)
2 x usb 2.0 port(s)(2 x type – a)
front usb port ( total 6 )
2 x usb 3.2 gen 1 port(s)(2 x type – a)
4 x usb 2.0 port(s)(4 x type – a)
software features
asus exclusive software
armoury crate
ai suite 3
– performance and power saving utility
turbov evo
epu
digi+ vrm
fan xpert
– ez update
asus cpu – z
ai charger
daemon tools
nortón anti – virus software (free trial for 60 days)
winrar
uefi bios
asus ez diy
– asus crashfree bios 3
– asus ez flash 3
– asus uefi bios ez mode
asus special features
asus 5x protection iii
– asus digi+ vrm
– asus languard
– asus overvoltage protectión
– asus safeslot core
– asus stainless – steel back i – o
asus q – design
– asus q – dimm
– asus q – slot
asus thermal solutión
– aluminum heatsink design
back i – o ports
1 x ps – 2 keyboard – mouse combo port(s)
1 x d – sub
1 x hdmi
1 x lan (rj45) port(s)
4 x usb 3.2 gen 1 (blue) type – a
2 x usb 2.0
3 x audio jack(s)
internal i – o ports
1 x cpu fan connector(s)
1 x chassis fan connector(s)
1 x usb 3.2 gen 1(up to 5gbps) connector(s) support(s) additiónal 2 usb
3.2 gen 1 port(s)
2 x usb 2.0 connector(s) support(s) additiónal 4 usb 2.0 port(s)
1 x m.2 socket 3 with m key – type 2242 – 2260 – 2280 storage devices support
(sata & pcie 3.0 x 4 mode)
1 x spi tpm header
4 x sata 6gb – s connector(s)
1 x s – pdif out header(s)
1 x 24 – pin eatx power connector(s)
1 x 8 – pin eatx 12v power connectors
1 x front panel audio connector(s) (aafp)
1 x clear cmos jumper(s)
1 x system panel connector
1 x com port header
1 x speaker connector
accessories
user’s manual
i – o shield
2 x sata 6gb – s cable(s)
1 x supporting dvd
1 x m.2 ssd screw package(s)
bios
256 mb flash rom – uefi ami bios
manageability
wol by pme – pxe
operating system
windows® 10 64 – bit
form factor
matx form factor
8.9 inch x 8.7 inch ( 22.6 cm x 22.1 cm )
